S10.1 MKII

2-Way Passive Speaker

The compact 2-way S10.1 MKII passive speaker is designated for a whole host of venues such as conferences, live events, public venues in which speeches are being made, among others.



Best advantages

Suitable for temporary and permanent audio installations

Integrated rigging hardware

Weatherproof foam (water, dust)



Related applications

Specifications

AES Power: 250 W / 8 Ω
Bandwidth (-6dB): 85 Hz - 20 kHz
Sensitivity: 98 dB / 1W @1m
SPL MAX level: 122 dB
Directivity (-6dB): 90° H x 90° V
LF: 1 x 10’’ vented enclosure
HF: Compression 1
Connections: 2 Speakon NL4MP
Rigging:
Fem. socket. ø 35mm,
2 x Rails type aerodeck (top)
1 x Single stud (rear)
15 mm baltic birch wood
Finished polyurethane painting
Dim. H470 x D355 x W330, 17 kg

Product compatibility

CT2.1

HSL48

MB1
