CX SERIES (3 x COAXIAL SPEAKERS + 1 x SUBWOOFER)

2-Way Amplified or Passive Coaxial Vented Enclosure Cabinets

The CX Series consists of 3 x coaxial 2-way active & passive bass reflex cabinets. The BR115P bass cabinet complements the 250W AES 8′, 10′, and 12′ coaxial reflex cabinets.



Key features

FaitalPRO loudspeakers

Pascal Audio amplification for active models

Baltic birch wood cabinets



Related applications

Specifications

FAITAL PRO loudspeakers (& B&C for the BR115P: bass cabinet)
PASCAL AUDIO for amplified models
- Baltic birch wood
- Finished polyurethane painting
- Ideal for: karaoke, pubs, restaurants, clubs, lounges...

Disponible Versions

CX8PCX10PCX12PBR115P
Nominal diameter200 mm (8")250 mm (10")300 mm (12")380 mm (15")
AES Power250 W250 W250 W700 W
Program power500 W500 W500 W1400 W
Maximum SPL122 dB124 dB125 dB125 dB
Sensitivity95 dB97 dB98 dB98 dB
Dispersion angle100°100°100 °Omnidirectional
Frequency range70 - 20 000 Hz65 - 20 000 Hz55 - 20 000 Hz45 - 250 Hz
Loudspeaker typeCoaxial
8" + 1,5 "
Coaxial
10" + 1,5"
Coaxial
12" + 1,5"
-
15"
Dimension (mm) H x D X W360 x 360 x 275400 x 350 x 324500 x 430 x 395510 x 500 x 450
